| Feature | Details |
|---|---|
| Dimensions | 250 cm (length) x 84 cm (width) x 133 cm (height) |
| Wheelbase | 175 cm |
| Ground clearance | 16.5 cm (9 cm at rear derailleur) |
| Turning radius | 8 meters |
| Weight | 85 kg (without doors and battery), 95 kg (fully equipped) |
| Max. load | 200 kg (rider + cargo), max. 120 kg on rear axle |
| Front suspension | Carbon leaf springs |
| Rear suspension | Mechanical springs with dampers |
| Wheels | 4 x 20” E-bike ready, puncture-proof |
| Brakes | Tektro hydraulic disc brakes |
| Gears | 9-speed rear derailleur |
| E-drive | ZF Sachs RS925 |
| Max. speed | 25 km/h with electric assistance |
| Range | Up to 75 km per battery charge |
| Battery | BMZ - 48V - 17Ah 814Wh |
| Lighting | 2 headlights (150 LUX each), 2 rear lights, 2 brake lights, 6 indicators, 2 daytime running lights |
| Additional lighting | Interior light |
| Mirrors | External on both sides |
| Windows | Scratch-resistant polycarbonate |
| Windshield wiper | Manually operated |
| Driver's seat | Ergonomic plywood or plastic folding seat with Ventisit cushion |
| Headrest | Yes |
| Airflow | Adjustable central air intake at the front, removable side windows |
| Frame | 6060 aluminum alloy with powder coating |
| Body | Fiberglass epoxy |
| Side doors | Fiberglass epoxy |
